waste tire recycling machine /rubber powder production line

advantage:

This production line including main machine and accessories equipment,It is mainly used to process 600-1200mm waste tires, the
final product is 5-30 mesh rubber powder, and the steel wire and fiber are separated at the same time. 99% purity rubber can be
obtained For powder particles, the configuration specifications of the main machine breaker in this production line determine the
size of the production capacity.
Product Description

Process flow:

waste tire→cutting diameter of hub→cutting strips→cutting blocks→separate steel wire→crush rubber blocks→making powder→magnetic
separation→final products(rubber powder)

1. Ring cutter

Function: will whole tire cutting into tire crown, the side of the tire and inner circle
Power
Blades rotating speed
Adapt tire
Productivity
Dimensions
Weight
3kw
15R/MIN
650-1200
30strips
1150*850*1200
0.5t

2. Strips cutter

Function: various tire, glue, glue board piece cut into long strips
Power
Productivity
diameter
Output size
Equipment size
weight
4kw
20strips/h
650-1200
25-55
1230*650*1580
0.8t

3. Rim cutter

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
Power
Productivity
Output size
Equipment size
Weight
7.5kw
0.8-1.0t/h
35*35
780*550*1210
0.8t

4. Steel wire separator

Function: tires circle wire centrifuges, mouth will tire of coarse steel mouth circle parts with rubber effective separation
Power
Blades rotating speed
Adapt tire
Productivity
Dimensions
Weight
11kw
18R/MIN
650-1200
1-2strips/min
1.7*1.2*1.3m
1500kg

5.Rubber crusher

Crush the rubber block into rubber powder and granule .we can produce the no-standard production as your requirement .
Type&Specification
XKP-400
XKP-450
XKP-560
Feeding size
3.5CM
3.5CM
3.5CM
Discharging size
10—30 mesh powder
10–30 mesh powder
10–30 mesh powder
Rubber crusher throughput(kg/h)
100–150kg
250—300kg
350—420kg
Motor power(kw)
45
60
75
Outside measurement(m)
4.1×1.8×1.9
4.4×1.9×1.9
5.5×2.2×2.1
Weight(t)
7.5
11
19

6. conveyor belt, oscillating screen, magnetic roller:

To separator the iron power and rubber power and screening the rubber power, make the big rubber power re-milling.

7. fiber separator:

separator the fiber from rubber power.
